Film Faced Plywood

Film faced plywood is a concrete shuttering plywood, with a smooth, double-sided phenolic film overlay and sealed edges. It is also a multipurpose and maintenance free cladding panel for the transport industry and agriculture.

Base plywood: poplar/birch/combi/hardwood core
Glue: W.B.P. glue (weather/ boil proof)
Film color: dark brown, black film. Other colors like yellow, green, grey, light brown can be special ordered.
Thickness: mm   4  6.5  9  12   15   18  21   24  27  30
Size:
1200   1200/1800/2400/2650/2700/3000/3660mm
1200   1220/1525/2440/3050/3660mm
1250   1250/2500mm
1500   1500/1800/2400/2700/3000/3600mm
1525   1525/2440/3050/3660mm
1875   1525/2440/3050/3660/3700mm
Other sizes available by order. Maximum standard thickness is 40mm.

The first measurement indicated the orientation of the surface veneer grain. Plywood can also be special ordered with a longitudinal grade orientation.

Quality standard: EN 13986: 2004
Structural plywood in external conditions (EN636-3S) complying with EN 636
Structural plywood in internal conditions (EN636-2S) complying with EN 636
Structural plywood in internal dry conditions (EN636-1S) complying with EN 636
All with formaldehyde class E1.

Application:
Smooth concrete form, cassette systems, transport equipment containers, trailer side boards, horse trailers, sliding doors.
